Table 6: MAP Gateway
Web Browser
Requirements for
Computers and
Handheld Devices
Computer:
Google
®
Chrome
™
54 and above is the preferred browser for MAP.
Windows Internet Explorer
®
11, and Apple
®
Safari
®
8 and above are
also supported.
Handheld Device:
The handheld device must be running iOS version 8.0 or later on an
Apple
®
iPhone
®
or iPod touch
®
; Android
™
versions 5.1 or later; or
using the browser Google Chrome 54 or above.
Note: Other web browsers may display the UI, but the functionality is not
guaranteed.
Purpose of control Operating control
Suffix field "V" digits Type
S, C, E Independently mounted
Construction of control
and whether the
control is electronic
P Free Standing / Hand Held
TYPE 1 or TYPE 2 action TYPE 1
External Pollution
Situation
Pollution Degree 2
Rated impulse voltage 330 V
15 VDC External Power
Supply (Not required
if module is provided/
shipped with power
supply)
Terminal J4:
SELV; Class 2 or LPS (Limited Power Source) ITE Equipment Power
Supply
Terminal J1:
Intended for connection to Johnson Controls field controllers
supporting the standard JCI SA Bus implementation
Compliance United States UL Listed File E107041, UL 60730-1, Automatic Electrical
Controls; UL 2043 (Stationary version only), Suitable for Use in Other
Environmental Air Space in Accordance with Section 300.22, (C) of the
National Electric Code.
Transmission Complies with FCC Part 15.247 Regulations for Low Power
Unlicensed Transmitters
Transmitter FCC Identification: OEJ-MAPWIFI
FCC Compliant to CFR 47, Part 15, Subpart B, Class A
Canada: Industry Canada IC: 279A-MAPWIFI
IC: RSS-210
cUL Listed File E107041, CAN/CSA E60730-1, Automatic Electrical
Controls
Europe: CE Mark—Johnson Controls declares that this product is
in compliance with the essential requirements and other relevant
provisions of the Radio Equipment Directive (RED), LVD Directive, and
the EMC Directive.
CE Emission: EN61000-6-3: 2007; Generic standards for residential,
commercial, and light-industrial environments. ETSI EN 301
489-1:2001-09, ETSI EN301 489-3:2001-11 (Class 2), IEC 60730-1/
EN60730-1
Australia and New Zealand: RCM Mark, Australia/NZ Emissions
Compliant.
27Mobile Access Portal Gateway Installation Guide
