10 ©2017 Johnson Level & Tool - Rev. 1
Manual vs. Self-leveling Operation
1. Turn the lock knob counter-clockwise to the “Off” position to lock
the compensator. The laser will be operating in manual mode and
will not be self-leveling.
2. Turn the lock knob clockwise to the “On” position to unlock the
compensator and allow the laser to self-level.
3. Place the laser on a relatively smooth, flat and level surface.
4. Set the lock knob to the “On” position.
5. Press the button to power on the laser.
6. Laser must be within ±3º of level for the self-leveling feature to
function properly. If the laser is tilted to exceed its self-leveling
range, it will stop rotating and will sound an intermittent beeping
sound.
Leveling the Laser for use in Vertical Mode
(Bubble Level Adjustment)
1. Turn the lock knob counter-clockwise to the
“Off” position to lock the compensator. The
laser will be operating in manual mode and will
not be self-leveling.
1658i-English_Manuals 1/11/17 11:50 AM Page 10
