Capacity kW 0.85* (+1.5**) 0.85* (+1.5**)
Energy Class (ERP) A+*** A+***
COP (ERP) 2.80*** 2.80***
Duct air flow (nom.) m³/h 300 300
Rated power input W 250 (+1500**) 250 (+1500**)
Current (nom.) A 1.16* (+6.5**) 1.16* (+6.5**)
Current (Rated.) A 1.81(+6.5**) 1.81(+6.5**)
Power supply
V/Ph/H
z
220-240~/1/50 220-240~/1/50
Max outlet water
temperature (with-
out using E-heater)
°C 60 60
Refrigerant
…/g
R134a/650 R134a/650
Rated water yield L/H 18.5 18.5
Max. Water operat-
ing pressure
Mpa 1.0 1.0
Rated water pressure Mpa 0.6 0.6
Set point relief valve Mpa 0.7 0.7
Sound power level dB (A) 46 46
Net weight kg
59.5
57.5
Net size（WxHxD） mm φ520x1368 φ560x1475
Package Size
（WxHxD）
mm 580x580x1515 610x580x1610
* Capacity and power input based on the following conditions: Ambient temperature 20°C,
water temperature from 10°C to 55°C.
**Related to the supplementary heater
