Johnson MANANTIAL Series User Manual

stick every half year and change it if it has been used out
！
How to replace the magnesium anode
:
- Turn the power of the unit ‘OFF’ and pull out the plug.
- Drain all the water out of the tank.
- Remove the old magnesium anode from the tank.
- Replace the new magnesium anode.
- Recharge the water.
Schematic overview of the water and refrigeration circuit
Choose the suitable unit
Please refer to the table below to choose the suitable unit.
Family members
Tank capacity
1 ~ 2 people
110L/150L
Note: The table is just for reference.
hot water
outlet
cold water
inlet
water tank
low pressure switch
temp
sensor
air inlet
compressor
evaporator
air outlet
temp sensor
2-way valve
electronic expansion valve
11
V.1
