CHAPTER 3:ENGINEERING MODE INSTRUCTION
3.5 P3 Mode
Current testing is mainly used to test if the motor current is too high.
When the returned number exceeds 100, the carrying digit will display “massage intensity”
(100~500).
D3 is a major test item; if the intensity is set to medium (air bag strength 2) and machine core
forward value is greater than 50, it is likely to generate error code D0 because the current is too
high to lower the sensitivity of induction mechanism.
