Johnson MISTRAL Series User Manual

1 PRODUCT OVERVIEW
This ceiling and floor type unit is used for indoor air quality regulation in various scenes.This appliance is intended to be used
by expert or trained users in shops, in light industry and on farms, or for commercial use by lay persons.
2 WARNING
This section describes important safety information.
Please read the Manual carefully, especially those operating standards with “Warning” or “Note” signs. Failure to abide by these
standards may lead to personal injury or damages to the unit or other items.
01
NOTE
All the illustrations of this manual are for explanatory purpose only. If the appearance, functions and physical objects
are inconsistent, refer to the actual product.
Air outlet
Air inlet
Product appearance(exposed)
Air outlet
Air inlet
Product appearance(exposed)
1
2
3
4
5
6
Operation and Installation Manual
Fastening screw
Three-way valve and its piping assembly
Auxiliary drain pan
Wired controller
7 Inlet hose
Footing
Pcs Accessories
1
Pcs 4
NO. Name
Schematic Unit Qty Remarks
To be purchased separately
To be purchased separately from
manufacturer
To be purchased separately from
anufacturer
To be purchased separately from
manufacturer
Set
1
1
Pcs 1
To be purchased separatelyPcs 1
To be purchased separatelyPcs 1
8 Outlet hose To be purchased separatelyPcs 1
9 Filter To be purchased separatelyPcs 1
10 Check valve (inlet and outlet pipes) To be purchased separatelyPcs 2
Set
11 1 To be purchased separately
Drain pipe Pcs
V.1
