542933-UIM-C-0112
2 Johnson Controls Unitary Products
SECTION I: GENERAL
The Touch Screen Communicating Control is designed to manage communicating system compo-
nents (including: heat pumps, air conditioners, air handlers and furnaces). In general, these compo-
nents are the variable speed modulating furnace and variable speed air handler, premium 15 and
18 SEER air conditioners or premium 13, 15 and 18 SEER heat pumps.
While the communicating system has been designed for easy installation, this document will pro-
vide the installer with a more detailed explanation of installation process.
SECTION II: SAFETY CONSIDERATIONS
This is a safety alert symbol. When you see this symbol on labels or in manuals, be alert to
the potential for personal injury and equipment damage.
Understand and pay particular attention to the signal words DANGER, WARNING, and CAUTION.
DANGER indicates an imminently hazardous situation, which, if not avoided, will result in death
or serious injury.
WARNING indicates a potentially hazardous situation, which, if not avoided, could result in death
or serious injury.
CAUTION indicates a potentially hazardous situation, which, if not avoided may result in minor or
moderate injury. It is also used to alert against unsafe practices and hazards involving only prop-
erty damage.
INSPECTION
The following list details the parts included in this kit. Examine the kit to insure that all parts are
included.
LIMITATIONS
The Touch Screen Communicating Control’s primary function is to command a system containing
communicating product.
Exceptions to this rule are:
• Installing a communicating variable speed modulating furnace with a non-communicating air
conditioner. In this case the variable speed modulating furnace relays 24 VAC outputs to the
non-communicating air conditioner (per communicated commands by the Touch Screen
Communicating Control).
• Installing communicating controls in non-communicating UPG products.
• Installing Communicating Interface Control (which converts communicating commands into
24VAC outputs).
Item QTY. Description
1 1 Touch Screen Communicating Control
2 1 Communicating Plug Harness
3 1 Screw and Anchor Hardware bag
4 1 USB Adapter
5 1 Installation Instructions
6 1 Owner's Manual
7 1 Quick Help Document
8 1 Warranty Certificate
9 1 Warranty Registration Card
