542933-UIM-C-0112
Johnson Controls Unitary Products 35
Brand Selection
This screen is used to select the desired brand to be displayed on the Touch Screen Communicat-
ing Control. There are three brands to choose from: York, Coleman, and Luxaire. The touch screen
is set by default to York. The brand selected will be displayed in the “sleep” screen as well as in the
top right corner in several screens (as the service mode short cut).
FORCED OPERATION: MASTER CONTROL
Giving the homeowner the ability to “Upgrade Firmware” may require that the Touch Screen Com-
municating Control re-enter the auto-setup process. The installer should be sure that the home-
owner is capable of this task before allowing this option. If the auto-setup is not executed
properly, the system may not operate as desired.
Forced operation is available in all communicat-
ing systems. The options and functions available
depend on system ID. Forced operation (Located
in the service mode menu screen) is a very pow-
erful trouble shooting tool. This function allows
the controller to command indoor and outdoor
operation. Forced operation is separated into
three different modes: Cool Mode, Heat Mode,
IAQ Mode.
When entering forced operation, normal operation of the system will be discontinued. This means
that the controller will not control equipment to maintain a set point, schedule, mode of operation,
etc. Forced operation is a deviation from normal operation and the system will only run when
commanded through the forced operation menus. Normal operation is restored when forced
operation is exited.
