19
20
Assemble Canopy
see images
11
-
12
Assemble & Detach Cupholder
see images
13
-
14
The completely assembled stroller is shown as
15
Stroller Operation
Adjust Backrest
see images
16
-
17
There are 4 recline angles for the backrest.
Recline Backrest
To recline the backrest, squeeze the recline handle on the
back of the seat, pull down on the backrest.
16
Raise Backrest
To raise the backrest, push up.
17
! Make sure the recline is set properly for use.
Use Buckle
see images
18
-
19
Release Buckle
Press the center button to release the buckle.
18
Lock Buckle
Match the waist belt buckle with the shoulder buckle
19
- 1,
and click into the center buckle.
19
- 2 A “click” sound means
the buckle is locked completely.
19
- 3
! To avoid serious injury from falling or sliding out, always
secure your child with harness.
! Make sure your child is snugly secured. The space between
the child and the shoulder harness is about the thickness of
one hand.
! Do not cross the shoulder belts. This will cause pressure on
a child’s neck.
Use Shoulder & Waist Harnesses
see images
20
-
23
! In order to protect your child from falling out, after your child
is placed into the seat, check whether the shoulder and
waist harnesses are at proper height and length.
20
- 1 Shoulder harness anchor A
20
- 2 Shoulder harness anchor B
20
- 3 Slide adjuster
For larger child, use shoulder harness anchor A and the
highest shoulder slots. For smaller child, use shoulder harness
anchor B and the lowest shoulder slots.
To adjust the position of the shoulder harness anchor, turn the
anchor to be level with the side facing forward. Thread it
through the shoulder harness slot from back to front.
21
Rethread it through the slot that is closest to child's shoulder
height.
22
Use slide adjuster to change the harness length.
23
- 1
Press the button
23
- 2, while pulling the waist harness to
proper length.
23
- 3
