REARWARD FACING MODE
34
33
Important
1. DO NOT use forward facing mode before the child's weight exceeds 9kg.
Child restraint in forward facing mode is dangerous for a child under 9kg.
2. When the child is suitable for both forward and rearward facing
modes, it is recommended to install this child restraint in the
rearward facing mode as it is relatively safer.
Choose the Installation Mode
Concerns on Installation
!
DO NOT install this child restraint on vehicle seats with Lap Belts. (Fig. 2)
!
This child restraint is only suitable for vehicle seats with 3-Point Retractor
Safety Belts. (Fig. 3)
!
DO NOT install this child restraint on vehicle seats that face sideward (Fig. 4)
or rearward (Fig. 5) with respect to the moving direction of the vehicle.
!
DO NOT install this child restraint on the front vehicle seats in case injuries
might happen to the child when there is an accident. (Fig. 6)
!
This child restraint must be installed on the rear vehicle seat. (Fig. 7)
!
DO NOT install this child restraint on movable vehicle seats or vehicle doors
during installation.
Installation for
Rearward Facing Mode
(for Child under 13kg / 0- 1.5 years old)
Reference age New born - 1.5 years old
Seat position Last position (with top blue diamond and bottom blue
diamond aligned, as Fig. 8)
!
Please install the child restraint on the vehicle seat, and then put the child in
the child restraint.
i. Proper Position of the Shoulder Harnesses
Please choose the proper pair of shoulder harness slots according to the
infant's height.
!
The shoulder harness slots shall be slightly below the infant's shoulder.
Shoulder harnesses too high or too low are not safe. (Fig. 9)
!
If the shoulder harnesses are not at proper height, the infant may be
thrown from the child restraint when there is an accident.
Child's
Weig ht
Installation
Mode
Figure for
Installation
Reference
Age
Seat
Position
Instructions
<13kg
Rearward
facing
mode
+
Small
Seat Pad
<1.5 years
Align top
blue
diamond
and
bottom
blue
diamond
9 - 18kg
Forward
facing
mode
1 year
to
4 years
Align top
red dot and
bottom red
dot for 3
adjustment
Disassemble the
Small Seat Pad
(Small Seat Pad
must not be used
for child over
1 year old)
寶寶
體重
安裝模式 安裝圖示 參考年齡 座椅段位 說明
未滿
13
公斤
後向
安裝模式
0 - 1.5歲
藍色方塊
上下對齊
9 -18
公斤
前向
安裝模式
1 - 4歲
紅色圓點
上下對齊
三段可調
段位
拆除小座墊
(1歲以上的寶寶
不能使用小座墊)
positions
0-6個月的寶寶
必須使用小座墊，
小座墊可輔助安
全帶綁緊寶寶，
並讓寶寶背部躺
平，避免脊椎彎曲
Small Seat Pad
must be used
for children 0-6
months. Small
Seat Pad can
help restrain
the child tightly
and level the
child's back to
avoid cyrtosis
