iii. Shoulder Harnesses Height Adjustment
Disassembly of the Shoulder Harnesses.
1. Pull up the webbing adjuster, while pulling the shoulder harnesses to the
proper position. (Fig. 12)
Fig. 12.1 Webbing adjuster
2. At the back of the seat, disassemble the two shoulder harnesses from
the T-shape steel plate. (Fig. 27)
3. Pull out the shoulder harnesses. (Fig. 28)
4. Thread the shoulder strap through the shoulder harness slots. (Fig. 29)
Assembly of the Shoulder Harnesses.
1. Choose the proper shoulder harness slots and thread the shoulder
straps through them. (Fig. 30)
!
It will affect the normal function of the harnesses with the rubber side
upward. (Fig. 31)
2. Thread the shoulder harness through the shoulder strap. (Fig. 32 )
!
To avoid the shoulder harnesses from getting twisted, please engage
the buckle first.
3. Thread the shoulder harness through the shoulder harness slot. (Fig. 33)
4. Assemble the shoulder harness on the other side following the above
steps.
1. DO NOT remove the shoulder straps as they are important for preventing
the slippage of the child.
2. Please assemble the shoulder straps first, then the shoulder harnesses.
3. During assembling, make sure the shoulder harnesses are not twisted.
Note
5. Thread the loops on the shoulder harnesses through the T-shape steel
plate at the back of the seat. (Fig. 34)
!
The end of the shoulder harness has two harness loops 1, 2.
!
For a smaller baby, use the upper harness loop 1, and the ends of
the shoulder harnesses must hang in front of the T-shape steel
plate (Fig. 35)
!
For a bigger baby, use the lower harness loop 2 (Fig. 36)
iv. Forward Facing Installation
1. Pull out the safety belt. Incline the child restraint rearward to any angle
and thread the belt through two forward red safety-belt slots at the back
of the child restraint shell. (Fig. 37)
When installing the child restraint in the forward facing mode, the vehicle
safety belts must pass behind the child restraint harnesses. (Fig. 38)
2. Buckle the vehicle belt. (Fig. 39)
3. Open the lock-off device and insert the safety belt through it. (Fig. 40)
4. While pressing the child restraint, pull the belts to fasten the child
restraint tightly and securely. (Fig. 41)
!
Please check by moving the child restraint back and forth.
!
The child restraint can not be used if the vehicle safety belt with female
buckle is too long to tie the base. ( Fig. 41.1)
1. Please adjust the shoulder harnesses to proper height (slightly above the
child's shoulder) before installing the child restraint, please refer to P. 39
(Proper Position of the Shoulder Harnesses) & P. 40 (Shoulder Harnesses
Height Adjustment).
2. Please adjust the child restraint to proper angle (3 positions for forward
facing mode). Angle indication: With the top red dot and the bottom red
dot aligned, as Fig. 25
3. When installing and adjusting the safety belts, make sure that both the
shoulder belt and the waist belt are not twisted and will not keep the
safety belts from being properly positioned.
Note
