USER MANUAL
16
STEP 2
Plug the Charging Connector: Open the socket’s cover and plug the charging connector
into the socket(IEC 62196-2), then plug the other charging connector into the electric
vehicle.
STEP 3
Charging: The green light (CHARGE) turns
to flash automatically, charging is in process. (e.g. AC1
STEP 4
Charging finished: When the charging is finished, the green light
(CHARGE) is constantly on. (e.g. AC1)
To Next Page
