USER MANUAL
6
3. Verify Contents
Check the box to ensure you have this installation guide and these parts:
No. Product Name Quantity Description
1 AC Charger 1 With attached input power cable
2 User Manual 1 Please read carefully before use
3 Wall-Mounted Bracket 1
For mounting the charger to the
wall/structure
4
M5 Anti-Theft Round
Head Screws
2
For securing the charger to the
Mounting Bracket
5
M6 Hexagonal Expansion
Screws
4
For installing the Mounting Bracket
to the wall/structure
6 Allen Wrench 1 For tightening M5 Screws
7
Corrugated Mounting
Template
1
For easy drilling of 4 screws holes
for wall-mounted bracket.
8 15m Signal Wire (Optional) Load balance signal line
Note: Please contact us if you are missing any of the parts in the list.
