USER MANUAL
11
6. Wire The Circuit
WARNING: This device must be grounded. Disconnect electrical
power prior to installing the charging station.
WARNING: Improper connection of the equipment-grounding
conductor would result in a risk of electric shock. Check with a
qualified electrician or serviceman if you are not sure whether
the product is properly grounded. Do not modify the plug
provided with the product – if it doesn’t fit the outlet, have a
proper outlet installed by a qualified electrician.
CAUTION: Use appropriate protection when connecting to the
main power distribution cable.
6.1 Incoming cable connection
For safe use of electricity, please set circuit
breaker protection in the input part of EV Charger
The wiring is not complicated, just need to follow
the instructions below:
For Single Phase
Connect the L1 lead to the grid L1, connect the N
lead to the grid N, connect the PE lead to the grid PE.
For Three Phase
Connect the L1 lead to the grid L1, connect the L2 lead to
the grid L2, connect the L3 to the grid L3,
connect the N
lead to the grid N, connect the PE lead to the grid PE.
