JoinTech EVCD2 Series - Product Introductions

USER MANUAL
4
2. Product Introductions
CAUTION: Avoid placing the charger near hot objects and at high
temperature locations and away from dangerous substances such as
flammable gases and corrosive materials.
2.1 Basic Interface
2.2 Basic Dimension
Enclosure
Wall-Mounted Bracket
Signal Check Indicator
AC2 Status Indicator
Rear Notch
Secondary Back Input
AC Power Cable
AC1 Status Indicator
LAN Cable Inlet
Load Balance Socket
IEC62196-2 Sockets
