USER MANUAL
5
2.3 Specifications
2.4 Dial Switch Setup Instructions
The maximum output current can be adjusted by dial switch
0:16A*2
1:32A*2
Model Number EVCD2
Rated Input Voltage 230VAC ± 10% / Single Phase
400VAC ± 10% / Three Phase
Rated Input Current 32A/64A
AC Power Frequency 50/60 Hz
Rated Output Power
7kW*2 11kW*2/22kW*2
Rated Output Current 32A*2 16A*2/32A*2
Input Protection UVP, OVP, OTP, RCD, SPD, Ground Fault Protection
Output Protection
OCP, Control Pilot Fault Protection
Output Interface
IEC62196-2 Socket
Storage Temperature
-40°C to +85°C
Operation Temperature
-30°C to +50°C
Relative Storage Humidity ≤95%
Relative Operation Humidity ≤95%
Connection Method WIFI/LAN
Network Transmission Rate 10M / 100M Base-T
Wireless Transmission
Protocol
802.11 b/g/n
Protection Level IK08 IP54
Altitude 2000m
