5. Mount The Charger
WARNING: In areas with frequent thunderstorms, add surge
protection at the service panel for all circuits. Ensure all power and
ground connections, especially those at the breaker and bus bar, are
clean and tight.
CAUTION: Not recommended to be installed in coastal environments
with high humidity or high dust.
STEP 1
Drill 4 Screw Holes with a diameter of 8.5mm and a depth of 55mm~60mm by using our
mounting template. Please drill screw holes in the direction of the template arrow.
