USER MANUAL
22
8.3 Fault and Warning Message
Fault Status Red Remark
Electronic lock fault Solid Red Reboot Recover
Voltmeter fault 1 flash followed by 3 sec pauses Auto Recover
Control pilot fault 2 flashes followed by 3 sec pauses
Auto Recover
(Pull out the charging connector)
Input UVP 3 flashes followed by 3 sec pauses Auto Recover
Input OVP 4 flashes followed by 3 sec pauses Auto Recover
OTP 5 flashes followed by 3 sec pauses Auto Recover
OCP 6 flashes followed by 3 sec pauses
Auto Recover
(Pull out the charging connector)
Ground fault 7 flashes followed by 3 sec pauses
Auto Recover
(Pull out the charging connector)
Relay fault 8 flashes followed by 3 sec pauses
Auto Recover
(Pull out the charging connector)
RCD abnormal 9 flashes followed by 3 sec pauses
Auto Recover
(Pull out the charging connector)
RCD self-test fault 10 flashes followed by 3 sec pauses R Recover
