Jonker Sailplanes JS-3 Rapture User Manual

JS-MD 3
Aircraft Flight Manual
MD10-AFM-00-001
Issue: 01
Rev. 00
Rev. Date: 14-Feb-20
Page 2–3
Table 2.2-2 below lists the maximum allowable airspeeds for each flap
setting:
Flap setting
Deflection (°)
V
FE
15 m
18 m
1
-3°
280 km/h / 151 kts
2
+0°
3
+5°
230 km/h / 124 kts
4
+13.5°
165 km/h / 89 kts
5
+16.6°
165 km/h / 89 kts
L
+20°
160 km/h / 86 kts
Table 2.2-2 Airspeeds for flap settings
The maximum allowable airspeeds for each flap setting are indicated on
the airspeed indicator (ASI) with white triangles next to the flap position
number, as indicated in Figure 2.2-1 (ASI in km/h) and Figure 2.2-2 (ASI
in knots).
Figure 2.2-1 ASI in km/h
Figure 2.2-2 ASI in knots
