Jonsered CS 2138 User Manual

14
DECLARATION OF CONFORMITY
relating to 2000/14/EC
EC Declaration of Conformity relating to 2000/14/EC
We, Electrolux Home Products, Inc., Texarkana, TX, 75501, USA, Tél. : +1 903 223
4100, declare under sole responsibility that the Jonsered model CS2138 chain saw was
assessed in accordance with Annex V of the DIRECTIVE and from serial numbers
2004--205(N or D)00001 and onwards, conforms to the provisions of the DIRECTIVE. The
net power is 1,8 kW . The measured sound power is 102 dB and the guaranteed sound
power is 118 dB.
Texarkana 04--07--23
Michael S. Bounds, Director
Product Safety and Standards
DECLARATION OF CONFORMITY
relating to 98/37/EC
Michael S. Bounds, Director
Safety and Standards
EC Declaration of Conformity (Directi
v
e98
/
37
/
EC,
A
nnex II,
A
) (Only applies to
Europe)
We, Electrolux Home Products, Inc., Texarkana, TX 75501, USA, Tel: +1 903 223
4100, declare under sole responsibility that Jonsered model CS2138 chain saw from
serial numbers 2004--205(N or D)00001 and onwards, follows the provisions of the
DIRECTIVES: 98/37/EC (machinery) and 89/336/EEC (electromagnetic compatibility),
including amendments and is in conformity with the following standards: ISO
11681--1:2004, EN ISO 12100--1:2003, EN ISO 12100--2:2003 and CISPR 12.
The supplied Chain Saw conforms with the sample that underwent the EC type
approval.
Notified body, 0404 the Swedish Machinery T esting Institute, Fyrisborgsgatan 3
S--754 50 Uppsala, Sweden, has carried out EC type approval. The certificate(s) are
numbered: 404/96/398.
Texarkana 04-- 07--23

Jonsered CS 2138 Specifications

Engine Specifications

cylinder volume	42 cm3
stroke	32 mm
idle speed	3000 rpm
recommended max speed, unloaded	13000 rpm
power	1.8 kW

Noise Levels

noise pressure level at operator’s ear	101 dB(A)
noise power level	95 dB(A)

Vibration Levels

front handle vibration level	5.5 m/s2
rear handle vibration level	8.5 m/s2

Fuel and Lubrication System

fuel capacity	0.38 litre
oil pump capacity at 8500 rpm	4 - 8 ml/min
oil capacity	0.2 litre

Chain/Bar Specifications

standard bar length	14/36 in/cm
recommended bar lengths	14/36 16/41 in/cm
usable cutting length	13.5/35 15.5/40 in/cm

Weight and Dimensions

weight without bar and chain	4.7 kg
pitch	0.375 inches
thickness of drive link	1.27 mm
