Symbols on the mac
hine:
W
ARNING! Chain saws can be
dangerous! Careless or improper use
can result in serious or fatal injury to the
operator or others.
Please read the operator’s manual
carefully and make sure you
understand the instructions before
using the machine.
Always wear:
• Approved protective helmet
• Approved hearing protection
• Protective goggles or a visor
Both of the operator
′
s hands must be
used to operate the chain saw.
Never operate a chain saw holding it
with one hand only.
Never let the guide bar tip come in
contact with any object.
WARNING! Kickback may occur when
the nose or tip of the guide bar touches
an object, and cause a lightning fast
reverse reaction, kicking the guide bar
up and towards the operator. May cause
serious personal injury.
Recommended cutting equipment
in this example: - Bar length 16
inches - Max. nose radius 10 Teeth
- Chain type Jonsered H25
Other approved bar and chain
combinations in Operator’s Manual.
Measured maximum kickback value with
brake for the bar and chain combination
on the label.
Measured maximum kickback value
without triggering the brake, for the bar
and chain combination on the label.
Chain brake, activated (right)
Chain brake, not activated (left)
Decompression v
alve:
Press the valve
to reduce the pressure in the cylinder and
make starting easier. You should always
use the decompression valve when
starting the machine.
Ignition;
choke:
Set the choke control
in the choke position. This should
automatically set the stop switch to the
start position.
Adjustment of the oil pump
Refuelling.
Chain oil fill.
Air purge.
Other symbols/decals on the mac
hine refer to special
certification requirements for certain markets.
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
