Jonsered CS2234 User Manual

Page E2 CS2234 STANDARD STARTER
CS2238
Position Article Quantity Notes Kit
1 545 00 80-28 KIT, STD STARTER CS2238, CS2238 S
2 530 01 59-20 1 SCREW SHOULDER 1,10
3 530 01 60-80 1 SCREW, ROPE RETAINER 1,10
4 530 05 78-90 1 PULLEY STARTER standard 1,10
5 545 01 00-12 1 HANDLE & ROPE assy 10
6 530 04 20-95 1 SPRING RECOIL 10
7 545 16 13-01 1 BAFFLE
8 545 16 12-01 1 FAN HOUSING 10
9 530 01 64-32 4 SCREW, FAN HOUSING 10
10 545 18 08-13 KIT COMPLETE CS 2234, CS 2238
11 545 16 59-83 1 DECAL CS2238
12 545 16 59-01 1 DECAL CS 2234

Jonsered CS2234 Specifications

General

Bar Length	14 inches
Weight	4.7 kg
Fuel Tank Volume	0.25 liters
Oil Tank Volume	0.2 l
Engine Displacement	34.4 cm³
Power Output	1.4 kW
Weight (excl. cutting equipment)	4.7 kg
Weight (without cutting equipment)	4.7 kg
Chain pitch	3/8 inch
