Page H CS2234 CARBURETOR AND AIR FILTER
CS2234S
CS2238
CS2238S
Position Article Quantity Notes Kit
1 574 71 94-02 1 CARBURETOR (ZAMA) Ref.
3 545 06 21-01 1 FILTER HOUSING
4 545 06 18-01 1 AIR FILTER
5 545 15 18-01 1 FILTER PLATE
6 530 01 61-01 2 NUT, CARB
7 545 06 19-01 1 ISOLATOR FILTER HOUSING
8 545 06 34-01 1 SWITCH, SPRING
9 545 06 17-01 1 SWITCH LEVER
10 545 06 16-01 1 CHOKE KNOB
11 545 06 15-01 1 CARB ADAPTOR SEAL
13 545 16 98-01 1 CARB ADAPTOR
15 545 03 37-01 2 STUDCARBURETOR
16 545 15 83-01 4 CARB ADAPTOR SCREW
17 530 01 60-80 1 SCREW SWITCH
18 545 07 49-01 1 TOP STUDCARBURETOR
19 545 08 18-92 1 GASKET KIT
20 530 01 63-49 1 SCREW, FILTER PLATE

Jonsered CS2234 Specifications

General

Bar Length	14 inches
Weight	4.7 kg
Fuel Tank Volume	0.25 liters
Oil Tank Volume	0.2 l
Engine Displacement	34.4 cm³
Power Output	1.4 kW
Weight (excl. cutting equipment)	4.7 kg
Weight (without cutting equipment)	4.7 kg
Chain pitch	3/8 inch
