Page G CS2234 MUFFLER
CS2234S
CS2238
CS2238S
Position Article Quantity Notes Kit
1 574 26 64-01 1 NUT, #1024 BRASS 8,9
2 545 07 69-01 1 EXHAUST PLATE 8,9
3 545 16 74-01 1 SCREENARRESTOR, Gasket 8,9
4 530 01 63-38 2 MUFFLER BOLT 5,9
5 545 03 27-01 1 MUFFLER ASSEMBLY 9
6 530 05 48-84 1 MUFFLER GASKET 5,9
7 545 06 69-01 1 MUFFLER BACK PLATE 5,9
8 545 00 80-27 1 KIT SPARK ARRESTOR 9
9 545 18 08-43 1 KIT MUFFLER COMPLETE

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Jonsered CS2234 and is the answer not in the manual?

Jonsered CS2234 Specifications

General IconGeneral
Bar Length14 inches
Weight4.7 kg
Fuel Tank Volume0.25 liters
Oil Tank Volume0.2 l
Engine Displacement34.4 cm³
Power Output1.4 kW
Weight (excl. cutting equipment)4.7 kg
Weight (without cutting equipment)4.7 kg
Chain pitch3/8 inch
