Page J1 CS2234 CYLINDER PISTON 34cc
CS2234S
Position Article Quantity Notes Kit
1 545 05 04-18 1 KIT, CYLINDER & PISTON
2 545 08 15-01 4 BOLT, CYLINDER 1
3 545 10 15-01 1 TRANSFER INSERT LEFT 34c 1
4 545 10 14-01 1 TRANSFER INSERT RIGHT 34cc 1
5 545 10 17-01 1 10,1
8 530 01 56-97 2 10,1
9 503 23 51-08 1 PLUGSPARK (RCJ7Y)
10 545 08 18-93 1 KIT PISTON 34cc 1
