Jonsered CS2234 User Manual

Page L CS2234
CHASSIS & HAND GUARD
CS2234S
CS2238
CS2238S
Position Article Quantity Notes Kit
1 574 41 71-01 1 HANDGUARD
2 545 12 73-01 1 BOSS SCREW, HANDGUARD
3 545 06 12-02 1 REAR WALL
4 574 22 71-01 1 SCREW, MTG REAR WALL
5 545 07 54-01 1 GROMMET, REAR WALL
6 545 07 14-01 1 PLATE BAR MOUNTING
7 545 07 13-01 1 CAP, SPRING HANDGUARD
8 545 07 12-01 1 SPRING, HANDGUARD POSITION
11 545 23 00-02 1 CHASSIS ASSEMBLY
13 529 31 03-01 2 BOLT, BAR 11
14 545 03 35-01 1 ASSY, VENT LINE 11
15 530 02 98-68 1 PLUG VENT (BRONZE) 11
16 530 02 61-19 1 CHECK VALVE (DUCK BILL) 11
17 530 02 11-32 1 LINERETURN PURGE 11
18 530 02 38-77 1 FITTING FUEL LINE 11
20 545 06 19-01 1 ISOLATOR FILTER HOUSING 11
21 545 07 08-02 2 ASSYOIL/FUEL CAP W/RET. 11
22 530 01 59-06 2 SCREW M5.28X1.81X16MM PLAS 11
23 545 03 38-01 1 ASS'Y FRONT ISOLATOR 11
25 545 06 31-01 1 REAR ISOLATOR SPRING 11
26 530 09 56-46 1 ASSY PICKUP 11
27 545 07 83-02 1 LINE, FUEL 11
28 530 01 58-14 1 SCREW CATCHER
29 530 02 98-50 2 CHAIN CATCHER
30 530 03 89-90 1 SPIKE 32
31 530 01 64-39 2 SCREW SPIKE 32
32 530 01 43-81 1 KIT SPIKE

Jonsered CS2234 Specifications

General

Bar Length	14 inches
Weight	4.7 kg
Fuel Tank Volume	0.25 liters
Oil Tank Volume	0.2 l
Engine Displacement	34.4 cm³
Power Output	1.4 kW
Weight (excl. cutting equipment)	4.7 kg
Weight (without cutting equipment)	4.7 kg
Chain pitch	3/8 inch
