jotron TA-7650C Maintenance And Repair Manual

85894_M&R_TA7650C_A 1-3
1.3.1 BITE alarm condition
PARAMETER:
Alarm criteria
Condition: Module:
Min Max Unit
PA_3V3
2.9 3.6 V PA
PA_5V
4.5 5.5 V PA
PA_12V
11 12.8 V PA
PA_28V
20 29 V PA
PA_CUR
0 10 A PA current drain PA
MOD_6V
5.0 7.0 V Modulator
MOD_LD_L01
Digital 3v3 - 3.3V Logic – alarm if unlocked Modulator
PA_TEMP
-25 +85 °C PA temperature PA
MOD_LEVEL_L01
-20 8 dBm Modulator
PA_5VN
-6.2 -4.0 V PA
PA_SWR
NA NA - Calculated SWR Main
