To escape or return to a higher level, push "CANCEL" (function key).
If the microphone is fitted with an internal loudspeaker the function TX SIDE
TONE has to be set OFF to avoid feedback.
Menus
PREV – Fast selection of channels
Select between present and previous channel by pushing the function key
"PREV".
BITE – Built In Test Equipment
This function menu will measure and display the parameters shown in table 2.
Table 2 indicates the limits for acceptable values for these parameters. If the limits
are exceeded an alarm will be displayed.
Measurement Normal Min Max
Temp PA - -20 °C +95 °C
Fwd Power 1W – 2,5W – 5W – 8W –10W 10W
Ref Power Depends on the antenna and forward power 0 The level of
forward power.
U Battery Depends on the power source 10.3 V 15 V
9 Volt 9 V 8,5 V 10 V
5 V Dig 5 V 4,3 V 5,6 V
5V analog 5 V 4,3 V 5,6 V
3 Volt 3 V 2,7 V 3,3 V
Current 0,4 A in receive 0,3 A 5 A (transmitting)
Modulation - 0% 100%
IF Current 6 mA
LNA Current 24.5 mA 10 mA 30 mA
RSSI 1.1 V at 1 uV - -
Temp LCD A few degrees above the ambient temperature -20°C +55°C
Table 2:
