8 99213_UM_TR710_D
Technical specifications
Frequency range: 118 - 137 MHz.
Channel separation: 25 kHz, 12.5 / 8.33 kHz. (Selectable)
Frequency steps: 25 kHz, 12.5 / 8.33 kHz
Preset channels: 63
Type of modulation: AM (A3E)
Monitor: In headphone and rear connector
Antenna connector: 50Ω, TNC-connector
Operating temperature: -20 to + 55°C
Storage temperature: -20 to + 70°C.
Operating voltage: 230/115 VAC ± 10% (external power supply)
11-15VDC
13.7VDC nominal
Output power is reduced at lower voltages
Power consumption: 10W, 80% modulation: < 50VA
Battery package: 12VDC, 4500mAh NiMh
Dimension: 8 cm (H) x 21 cm (W) x 22 cm (D)
Weight: 1.8 kg, (2.9 kg with battery)
Hours of operation: Dutycycle 10/90% 10W (mode M and MD) 6.5 hours.
2.5W (mode MP) 8.5 hours.
Output power: 10W. Adjustable. (40W PEP)
Sensitivity: 10 dB SINAD at 1µV pd, 30 % modulation
