MUTE ON/OFF
When the function is ON the transmitter will
mute low audio signals.
INPUT MIC/LINE
Select between microphone input or line input.
When line input is selected, "LINE" is shown in
the standard screen picture.
(Line is used for remote operation).
TX POWER
Adjust the output power of the transmitter.
Range: 1 to 10 watt, (40 w PEP).
Steps: 10, 25, 50, 80, and 100 %.
TIME OUT
This function set the maximum time for how
long the transmitter can be keyed continuously.
Range: 0.5 – 5 minutes, steps of 30 seconds.
This function can also be turned off.
