3.2 Rear connecƟons
3.2.3 LAN connector (RJ45)
The LAN connector is of standard RJ45 type and can be connected to a switch, router or directly to a computer,
using a standard Ethernet cable. The pin-out of the LAN connector are the standard pin-out used in most
ethernet networks. This interface can be used for remote monitoring with the Jotron RCMS system. The LAN
interface can also be used for recording and remote operaon with the VoIP opon enabled.
Table 18: LAN interface connector, pin out
LAN interface connector
Name Pin Funcon
LAN_TXP 1 Tx data
LAN_TXN 2 Tx data
LAN_RXP 3 Rx data
LAN_D3P 4 NC
LAN_D3N 5 NC
LAN_RXN 6 Rx data
LAN_D4P 7 NC
LAN_D4N 8 NC
3.2.4 I/O connector (RJ45)
The I/O connector is a RJ45 type and contains different signals for connecng to external equipment. It can
be used to connect an external speaker, and there are also 600 Ω audio input/output, available for connecng
for example analog recording systems. It has also two configurable inputs/outputs which can be use as status
indicators or input signals such as ”Low Power” (frequently used in offshore installaons) or as an external
key input. This connector is also used to connect the baery package (BU-872) for communicaon between
the radio and the baery package.
All funcons are described in the table below:
Table 19: I/O connector, pin out
I/O connector
Name Pin Funcon Dir Level Max
V
Max
mA
EX-SPEAKER+ 1 To external speaker+ O 5W@8Ω
EX-SPEAKER- 2 To external speaker- O 5W@8Ω
MONITOR 3 To tape recorder etc. 600 Ω
unbalanced
O -46 to 0 dBm
24 jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB
