Jøtul F 305 - Fitting a flue pipe with a rear outlet

14
ENGLISH
Fig. 20
A
B
4. Fit the log retainer (A) on the knobs (B).
4.6 Fitting a fl ue pipe with a rear outlet
The product is supplied from the factory with the smoke outlet
fi tted for the top outlet. If you want a rear outlet, proceed as
follows:
Fig. 21
ABB
1. Place the product in the correct position. See fi g. 1.
2. Unscrew the screws (B) and remove the exhaust defl ector (A).
Fig. 22
A
3. Unscrew the smoke outlet (A) from the top outlet.
