Jøtul F 305 User Manual

16
ENGLISH
Fig. 27
A
A
A
9. Cut the rear outlet in the points (A) in the outlet and remove
the cover.
Fig. 28
A
A
A
10. Do the same to the inside part of the convection plate.
Fig. 29
11. Hook the convection plate to the product again and secure
using the same four screws.
Fig. 30
A
B
12. Place the gasket (B) on the edge of the fl ue pipe (A).

Jøtul F 305 Specifications

General

Type	Wood Stove
Material	Cast Iron
Flue Outlet	Top or Rear
Flue Size	6 inches
EPA Certified	Yes
Emissions	2.5 g/h
Heating Capacity	up to 1, 200 sq. ft.
