22
Jøtul F 370 U.S. 10036803_P12
Only use replacement parts provided
through your authorized Jøtul dealer.
8.1 Jøtul F 370 Parts List
No. Description Part Number
46. Smoke Outlet Cover Plate 10441112
47. Air Valve - BP 22329892
48. Gasket, Air Tube - Manninglass 223310
49. Burn Plate, Rear - Skamol 223293
50. Air Manifold, Front 10433912
51. Burn Plate, L & R Side - Skamol 221805
52. Baffle 223292
53. Washer, Ø6.2 x 12 x 1.8 Brass 128632
54. Burn Plate, Lower - L & R, cast iron 10447512
55. Grate 10434912
56. Bottom Plate, Inner 10434812
57. Screw, Hex Cap Flange, M8 x 25mm 117876
59. Screw, Hex Cap Flange, M6 x 10mm 9962
60. Screw, Countersunk Cap Internal Hex - M8 x 16mm 117739
61. Glass, Side - Inner, L & R 221867
62. Gasket, Glass Holder LD 250-2 Ø6,4 x 40mm 200024
63. Gasket, Glass Holder LD 250-2 Ø6,4 x 1000mm 200024
66. Washer, Ø6 x Ø12 x 0.5mm 117588
67. Glass Clip, Side Inner Glass - inc. gasket 153620
68. Screw, Cylinder Head Internal Hex - M6 x 12mm 118231
69. Glass Clip, Door Glass 128412
70. Screw, Countersunk Cap Internal Hex - M6 x 10mm 117977
71. Door Hinge, Steel (2) - BP 22166292
73. Door Handle 223309
75.* Bolt, Serrated Flange Hex Hd, M6 x 20mm Blk, (2) 117117
76. Door Latch Assembly 221659
77. Gasket, Door to Front Plate - LD 375-2 Ø9, 5 x 2100mm 100038
78. Door, BP 10446392
79. Door Glass, Ceramic 221648
80. Gasket, Door Glass - LD 250-2 Ø6,4 x 2000mm 200024
81.* Acorn Nut, (2) 118253
82. Door Handle Bumper 221897
83.* Bolt, Lag 3/8” x 2.5”, 1 118252
84.* Bracket, Anchor, 1 224499
85. Upper Hinge Assembly 157186
86. Upper Door Catch Assembly 157187
87.* Outlet Adaptor Asy. inc. Locking Rod and Cotter Pin 222793
106. Pedestal Top 10448712
109. Brake Cover - BP 10453692
110. Pedestal Bottom - BP 10449192
112. Screw, Hex Cap - M8 x 16 9912
113. Pedestal Side - BP 10448892
* Adaptor Kit - inc. Outlet Adaptor and Pedestal Anchor Hardware 157373
No. Description Part Number
1. Screw, Hex Cap, M8 x 20 117875
2. Screw, Hex Cap, M8 x 30 117877
3. Air Manifold, Rear 10448312
4. Rear Plate 10446718
6. Glass Holder, Right - inc. 5(1),30,62,63,67,68 (2 pcs.ea.) 156844
7. Side Plate, Right - BP 10446592
8. Gasket, Bottom Plate - LD 250-2 Ø6,4 x 930mm 200024
9. Gasket, Ash Pan Rider - LD 250-2 Ø6,4 x 785mm 200024
10. Bottom Plate 157147
11. Nut, Flange Hd Hex - M6 117968
12. Lock Lower Door 10447318
13. Sleeve, 2 x 15 mm 126109
14. Cover, Side Bolt 10460212
15. Screw, Hex Cap Flange - M6 x 16 99625
16. Screw, Phillips - M6 x 12mm 117976
17. Nut, Hex Cap Flange Hd, M8 117881
18. Sleeve, 10 x 8.2 x 10 mm Steel 223324
19. Screw, Socket Hd Cap, M6 x 35 117789
21. Secondary Air Manifold Assembly, Top 222786
22. Secondary Air Manifold, Rear 222787
23. Primary Air Tube 222797
24. Door Hinge, Lower / Cast Iron 10447218
26. Front Plate, BP 10446692
28. Ash Pan, Complete Assembly 157180
29. Screw, Countersunk Internal Hex, M8 x 40 116913
30. Gasket, V-125 x 40mm 127215
31. Gasket, Side Glass - Outer, toward Front 200024
32. Gasket, Side Glass - Outer, toward Side 200024
33. Side Plate, Left - BP 10446492
34. Glass, Side Outer -Rt & Lt 222157
35. Glass Holder, Left - inc. 5(1),30,62,63,67,68 (2 pcs.ea.) 156845
36. Handle Shield 223294
37. Screw, Hex Cap Flange M8 x 40 117879
38. Gasket, LD 250-2 Ø6 -4 x 600mm 200024
39. Air Outlet, Top - BP 10441692
40. Top Outlet Filler - BP 10441792
41. Top Plate, Upper - BP 10447092
42. Smoke Outlet, Ø150 mm 156240
43. Top Plate, Lower 10433818
44. Push Nut, Ø6 x Ø15 mm Blk 117859
