8
Jøtul F 370 U.S. 10036803_P12
The connector pipe or thimble sleeve must not
protrude into the flue liner or otherwise restrict draft.
Use refractory cement to seal the seam between the
chimney connector, sleeve, and thimble.
Do not connect this stove to a chimney flue servicing
another appliance of any kind.
Prefabricated Chimneys
When connecting the stove to a prefabricated metal
chimney, always follow the manufacturer’s instructions
and be sure to use all components that are required. This
usually includes a “chimney connector adaptor” that
is secured to the bottom section of the prefabricated
chimney and allows the chimney pipe to be secured
according to the manufacturer’s specifications. See fig. 5.
Figure 5. Connection to prefabricated chimney.
Listed Chimney Cap
Storm Collar
Flashing
Chimney
Connector
Adaptor
Ceiling
Joist
Type HT
Listed
Stainless
Steel
Chimney
Insulation
Shield
Ceiling Support
Package
