13
STEP 3
Fold the scooter
To fold the scooter, pull out the
fold knob as shown below [Fig
4.1.5]. At the same time gently
lower the seatback down into its
folded position [Fig 4.1.6].
[Fig 4.1.5] [Fig 4.1.6]
Now with the seat folded, loosen the tiller
adjuster knob and gently lower the tiller into
the folded position [Fig 4.1.7]. The tiller
handles should be able to rest between the
chassis as shown below. Re-tighten the tiller
knob to hold the tiller into position. This will
then allow you to pull the scooter on its rear
tip wheels as shown in Storage and Travel.
[Fig 4.1.7]
STEP 4
Storage and Travel
With the tiller tightened in the
folded position, you can now lift
the scooter onto its end for both
storage and travel. You are now
able to pull the scooter along on
its rear anti-tip wheels as shown.
CAUTION! Lifting weight
beyond your physical capacity
may result in personal injury. Ask
for assistance when necessary
while disassembling or
assembling your scooter.
[Fig 4.1.8] [Fig 4.1.9]
INSTALLATION AND ADJUSTMENT
