14
4.2 Mounting and removing the battery
4.2.1
Insert battery box
[Fig 4.2.1] [Fig 4.2.2]
To insert the battery box,
simply place it into position
and push forward as
shown below [Fig 4.2.1],
gently lowering it into
position. Make sure the
rubber protector flap
remains on top of the
battery box.
4.2.2 Remove battery box
To remove the battery box, push the box forward against the sprung
connectors and then lift up to release the box [Fig 4.2.2].
Note: When removing and mounting the battery, please make sure that
the switch is in the "OFF" state. [Fig 4.2.3]
[Fig 4.2.3]
4.3 Adjusting the backrest
4.3.1 Before driving, be sure to adjust the position of the backrest strap. The
concave side of the backrest strap should face the back (as shown in the
pictures below). Make sure the OFF ON In switch is in the "OFF" position. [Fig
4.2.3]
INSTALLATION AND ADJUSTMENT
