Joy-it DPS5015 - Connection Details

DPS5015
Published: 22.11.2018 Copyright by Joy-IT 4
First connect the display module with the enclosed cables to the corresponding LCD and key interface. In
the next step, you can connect the inputs and outputs to the device via the screw terminals.
3. CONNECTION DETAILS
IN+ Posive Input
IN- Negave Input
OUT+ Posive Output
OUT- Negave Output
