On the foiled cover you will find a few holes with numbers above the
center. These numbers correspond to the numbers that you can find at
the bottom le.
Mounting holes
The mounting holes are designed to mount single-board computers and
oer the possibility to mount dierent models like the Raspberry Pi or
Banana Pi. The various single-board computers that can be mounted
with the respective associated holes are listed below.
2. NUMBERING OF THE MOUNTING HOLES
1. GENERAL INFORMATION
Dear Customer,
thank you for choosing our product. In the following, we will show you
what to pay attention to during commissioning and use.
If you encounter any unexpected problems during use, please feel free to
contact us.
1 2 3 4
BananaPi Raspberry Pi A+ Raspberry Pi A Beaglebone Black
BananaPi-M3 Raspberry Pi B+ Raspberry Pi B
BananaP1-M2u Raspberry Pi 2B
Raspberry Pi 3B
Raspberry Pi 3A+
Raspberry Pi 3B+
Raspberry Pi 4B
BananaPi-M2-Berry
BananaPi-M5
