7.2 Settings
yyy
yyyy
[III] Receive Port Setting (RX Port)
Select ports for receiving signals from sensors.
There are two methods for receiving signals: specifying a port for each sensor, or using the automatic
recognition function without specifying ports.
Procedures 1. Open the Serviceman Menu.
2. Open the RX Port menu by performing the following menu operation.
2. Installation Menu
→ 9. Next
→ 5. LAN Port Setting
→ 2. RX Port
3. Select ports for each sensor.
Available sensor signals
Heading, Speed, AIS, GPS, DLOG, Alarm, Depth, Temperature, Wind, Current, ROT,
RSA, Time Zone, Date/Time
Available ports
When the automatic recognition function is used : AUTO
When ports are specified : User Setting, Serial, LAN, LAN(GPS),
LAN(Ship’s Clock)
Behavior pattern of selectable ports
AUTO : The system use data from JRC-LAN preferentially
7
User Setting : The system use the port selected by "3.14.1 Receive
Port Setting (RX Port)". The system use data from
JRC-LAN or sensor connected directly.
i
Own : The system use data from sensor connected to the
system directly.
LAN : The system use data from JRC-LAN.
LAN(GPS) : The system use GPS data from GPS connected to
JRC-LAN
ii
.
LAN(Ship's Clock) : The system use ship's clock data from ship's clock
connected to JRC-LAN
ii
.
i. In order to set "3.14.1 Receive Port Setting (RX Port)", select User Setting
in advance.
ii. LAN(GPS) and LAN(Ship's Clock) are selectable signals for
Time Zone and Date/Time.
7-28
