11.13 PLOTTER
(1) Plotter (Normal) (Synthesis mode)
Projection : Mercator projection (Latitude 85 degree or less.)
Scale : Radar synchronize range scale
Own ship track : 1 color(Cyan)
Interval of save 3/5/10/30 sec, 1/3/5/10/30/60 min or
every 0.1/0.2/0.3/0.5/1/3/5/10 NM and Off
Capacity 7,000 points
Cursor mark : 7 colors
Capacity of cursor mark : 2,000 points
Variety of cursor Mark : 29
Line : 7 colors
Capacity of line : Include in cursor mark
Variety of line : Solid line, broken line, alternate long
and short dash line
Coastline data : Coastline ROM Card (Option) (ERC, JRC, C-Map NT+)
One selected depth contour can be displayed.
External memory : Memory card (Option)
Position correction : Latitude / Longitude correction
Radar video synchronize range scale coast line by
manual. (Synthesis mode)
(2) Plotter (Option NDB-34A) (Synthesis mode, Plotter mode)
Projection : Mercator projection (Latitude 70 degree or less.)
Scale : Synchronize range scale (Synthesis mode)
1/1,000 to 1/10,000,000 are continuously selected. 10
stage can be changed (preset can be used). (Plotter
mode)
Own ship track : 7 colors.
Interval of save : 3/5/10/30 sec, 1/3/5/10/30/60 min or
every 0.1/0.2/0.3/0.5/1/3/5/10 NM and Off
Capacity of own ship track : 7,000 points
Cursor mark : 7 colors
Capacity of cursor mark : 20,000 points
Variety of cursor Mark : 29
Line : 7 colors
Capacity of line : Include in cursor mark
Variety of line : Solid line, broken line, alternate long
and short dash line
Coast line data : Coast line ROM card (Option)(ERC, JRC, C-Map NT+)
Selected one depth contour can be displayed.
External memory : Memory card (Option)
Waypoint and route : Waypoint can be set up to 999 points.
Information of waypoint : Azimuth, distance and the
time to required destination.
Setting of sea route : 10 sea routes. (20 destination for
one route can be set.)
Alarm of route : Waypoint arrival / break off, Route
arrival / break off
11
Position correction : Latitude / Longitude correction
Radar video synchronize range scale coast line by
manual. (Synthesis mode)
11-14
