JRC JMA-5322-9 User Manual

MAIN MENU(RADAR MENU key)
-> Press RADAR MENU again
2 RADAR Menu
－
3 TXRX Setting
－
1 PRF Fine Tuning → Section 3.8.3
2 Stagger Trigger → Section 3.8.3
4 PRF → Section 3.8.3
5 Ice Class Standby Mode → Section 3.8.3
3 Multi Window Setting
－
1 DIR/DIST EXP Display → Section 3.8.8
2 Numeric NAV INFO → Section 3.8.8
3 Depth Graph Setting
－
1 Depth Graph Display → Section 3.8.8
2 Depth Range → Section 3.8.8
3 Time Range → Section 3.8.8
4 Depth Unit → Section 3.8.8
4 Wind Graph
－
1 Wind Graph Display → Section 3.8.8
2 Wind Speed Unit → Section 3.8.8
5 TEMP Graph Setting
－
1 TEMP Graph Display → Section 3.8.8
2 TEMP Graph Color → Section 3.8.8
3 TEMP Range
－
1 Temperature setting (MIN) → Section 3.8.8
2 Temperature setting → Section 3.8.8
3 Temperature setting → Section 3.8.8
4 Temperature setting → Section 3.8.8
5 Temperature setting → Section 3.8.8
6 Temperature setting (MAX) → Section 3.8.8
4 Time Range → Section 3.8.8
6 Course Bar Setting
－
1 Course Bar Display → Section 3.8.8
2 Autopilot Course → Section 3.8.8
3 ROT Scale → Section 3.8.8
4 NAV Equipment Setting
－
1 GYRO Setting → Section 3.4.16 → Section 7.1.7
2 MAG Compass Setting
－
1 Heading Correction → Section 3.4.18
2 Correct Value → Section 3.4.18
3 Set/Drift Setting
－
1 Correction → Section 3.4.19
2 Set → Section 3.4.19
3 Drift → Section 3.4.19
4 GPS Setting
－
1 GPS Process Setting
－
1 Position → Section 3.4.20
2 Exclusion → Section 3.4.20
3 Geodetic → Section 3.4.20
4 Antenna Height → Section 3.4.20
5 Fix Mode → Section 3.4.20
6 DOP Level → Section 3.4.20
7 Position Average → Section 3.4.20
8 Master Reset → Section 3.4.20
9 Send Data → Section 3.4.20
2 DGPS Setting
－
1 Mode → Section 3.4.21
2 Frequency → Section 3.4.21
3 Baud Rate(BPS) → Section 3.4.21
4 DGPS Mode → Section 3.4.21
5 Send Data → Section 3.4.21
3 SBAS Setting
－
1 Mode → Section 3.4.22
2 Ranging → Section 3.4.22
3 NG SBAS → Section 3.4.22
4 SBAS Select Mode → Section 3.4.22
5 SBAS No. → Section 3.4.22
6 Send Data → Section 3.4.22
4 GPS Status → Section 3.4.23
5 Weather INFO Setting
－
1 Display Weather INFO
2 SEL Observation Place
3 RX Message Display
4 RX Buzzer
6
RX Port －
1 Heading
→ Section 3.14.1
2 Speed
→ Section 3.14.1
3 AIS
→ Section 3.14.1
4 GPS
→ Section 3.14.1
5 DLOG
→ Section 3.14.1
6 Alarm
→ Section 3.14.1
7 Depth
→ Section 3.14.1
8 Temperature
→ Section 3.14.1
9 NEXT
↓
1 Wind
→ Section 3.14.1
2 Current
→ Section 3.14.1
3 ROT
→ Section 3.14.1
4 RSA
→ Section 3.14.1
5 Time Zone
→ Section 3.14.1
