JMA-9100/7100 Installation Manual > 3.INSTALLATION OF DISPLAY UNIT > 3.12 DISPLAY UNIT LEDS FOR VARIOUS SIGNALS
3－39
3
3.12 DISPLAY UNIT LEDS FOR VARIOUS
SIGNALS
Terminal board circuit CQD-2097 is equipped with LEDs to display operating
conditions.
Fig 3-34: Display unit LEDs
