JMA-9100/7100 Installation Manual > 4.INITIAL SETTING > 4.12 INITIALIZATION OF SCANNER OPERATION TIME
4.12 INITIALIZATION OF SCANNER
OPERATION TIME
This apparatus accumulates and stores the following operation time in the scanner.
• Transmission time
• Motor rotation time
The above accumulated time is initialized when magnetron is replaced, or an
scanner motor is replaced.
[I] Transmission time (Clear TX Time)
Transmission time of the scanner is initialized.
When magnetron is replaced, initialize transmission time according to the
following procedures.
Procedures
1) Open the [Service Man Menu] screen.
2) Open the [1.Clear TX Time] screen according to the operation shown below.
3) Select YES on the confirmation screen.
Transmission time stored in the control circuit located in the antenna is initialized
to 0.
3. Maintenance Menu
→
5. TXRX Time
→
1. Clear TX Time
