JMA-7100 Instruction Manual > 11.SPECIFICATION > 11.10 SCANNER UNIT (NKE-1129-7/9)
11.10 SCANNER UNIT (NKE-1129-7/9)
SCANNER UNIT NKE-1129-7/9
Dimension 7ft Height 536 x Swing Circle 2270 (mm)
9ft Height 536 x Swing Circle 2825 (mm)
Mass 7ft Approx.51kg
9ft Approx.53kg
Polarization Horizontal
Directional Characteristics Horizontal beam width
Vertical beam width
Side lobe Level
: 1.0° (7ft)
: 0.8° (9ft)
: 20°
: below -26dB (within +/-10°)
: below -30dB (outside +/-10°)
Revolution Approx.24rpm
Power Supply for Motor
AC100 - 115V、50/60Hz、1φ or
AC220 - 240V、50/60Hz、1φ
Maximum Wind Velocity 51.5m/s (100knots)
