JMA-7100 Instruction Manual > A.NQE-3141 Interswitch Unit > A.2 INTERSWITCH OPERATION
A.2.2 Inter Switch Menu
The Inter Switch Menu can be opened only when the transmission standby state.
Procedures
1) Press the [TX/STBY] key to stop transmitting.
The transmission standby state will be placed.
2) Move the cursor onto the Interswitch connection change (upper
left of the display), and left-click.
The Inter Switch Menu will appear.
Exit
1) Left-click the button.
The Inter Switch Menu will close.
Inter Switch Menu (with 2 Display Units)
0.Exit
b. Set c.Exit
Current
connection
status
a. Connection
pattern
Display unit
in operation
