JMA-9100/7100 Installation Manual > 3.INSTALLATION OF DISPLAY UNIT > 3.2 INSTALLATION OF AC-DC CONVERTER NBA-5135
3ļ¼19
3
Fig 3-18: Installation 1 of NBA-5135 (NCD-4790)
Fig 3-19: Installation 2 of NBA-5135 (NCD-4790)
Connect terminal block TB521 located at the upper part of NBA-5135 to CBD-
1661. Use the H-7ZCRD1342 (W406) cable (No.5 gray, thin, 60cm in
Table3-1ļ¼
NBA-5135 Packing List
). See Section 3.2.3 NCD-4990.
Terminal block TB522 located at the lower part of NBA-5135 is a DC output
terminal block. For the wiring procedure, see NCD-4990 in Section 3.2.3 NCD-
4990.
Confirm proper connection by referring to Section 6.3 INTER-BOARD
CONNECTION DIAGRAM.
ä½æēØććŖććć¤ćć³
ćÆćŖćććå¤ćć¦ććć
Remove the unused
Nylon clip.
ļ¼ļ¼ ć±ć¼ćć«ćå¤ć
Disconnect these cables
ļ¼ACć±ć¼ćć«ćDVIć±ć¼ćć«ć
ćć”ć³ć¢ć©ć¼ć ć±ć¼ćć«ć
ęä½éØć±ć¼ćć«ćé»ęŗćć£ć«ćæć±ć¼ćć«ļ¼
ļ¼ļ¼ćć¹ćå¤ć
Remove the 8 screws.
ćććļ¼8-NB5X10ļ¼
ļ¼ļ¼å¦ēéØć©ććÆćåę¹ć«å¼ćåŗććć
Pull out the rack of the radar process
unit to the front.
TB521
TB522
To Next Page
