4.4 RANGE ADJUSTMENT
Adjust the range so that the range of the target on the radar video screen is
indicated correctly.
Procedures
1) Search the radar display for a known target of which range has been
confirmed.
2) Open the [Service Man Menu] screen.
3) Open the [3.Range Adjustment] screen according to the operation shown
below.
For how to input values on the value input screen, see Section 3.3.4 in the
instruction manual.
4) Operate the + or - button to set the range adjustment value so that the
target measured in procedure 1 is located in the appropriate range.
5) Left-click the ENT button to confirm the value.
1. Adjust Menu
ā
3. Range Adjustment
To Next Page
