JMA-9100/7100 Installation Manual > 3.INSTALLATION OF DISPLAY UNIT > 3.2 INSTALLATION OF AC-DC CONVERTER NBA-5135
3.2.6 NCD-4790T
In the case of the desktop display unit NCD-4990T, NBA-5135 must be installed
outside the processing unit NDC-1399-9. The connection cable is 3 meters long.
NBA-5135 cannot be installed in a location which exceeds 3 meters from the
processing unit NDC-1399-9.
Install terminal block TB401 (No.6 and 8 in
Table3-1ļ¼ NBA-5135 Packing List
)
in the processing unit. See Section 3.2.4 NCD-4990T.
Connect W407 and W408 (No.3 and 4 in
Table3-1 ļ¼ NBA-5135 Packing List
).
See Section 3.2.4 NCD-4990T.
