JMA-9100/7100 Installation Manual > 1.EQUIPMENT COMPOSITION > 1.2 LIST OF CIRCUITS
1－5
1
Table1-6： JMA-9132-SA SCANNER UNIT
NKE-1130-1 NKE-1130-2
SCANNER
UNIT
SCANNER UNIT
INTERCONNECTION
CAX-13
RADIATOR CTG-270
SAFETY SWITCH CSD-656
ENCODER CHT-71A
MOTOR MDBW10823
AC100V MOTOR DRIVER
7EPRD0035
AC220V MOTOR DRIVER
7EPRD0034
BREAK CIRCUIT CFA-255
BREAK CONTROL CIRCUIT
CCB-655
BREAK UNIT NZR-17
MODULATOR UNIT NMA-551-1
MODULATOR UNIT
INTERCONNECTION
CMB-406
MODULATOR CIRCUIT CPA-264
RECEIVER CONTROL
UNTI
NZT-1130
RECEIVER UNIT NRG-229
RECEIVER UNIT
INTERCONNECTION
CMA-902
IF CIRCUIT CAE-499
RF CIRCUIT CAF-595
T/R CONTROL CIRCUIT CMC-1205R
RELAY FILTER CIRCUIT CSC-656
POWER SUPPLY CIRCUIT
CBD-1682A
HEATER CONTROL PART
CHG-215
PERFORMANCE MONITOR
NJU-84
DISPLAY
UNIT
NCD-4990/T
